LT/HT Shackle Insulator
| Applicable Standard | IEC-60383/IS-1445 |
|---|---|
| Power Frequency withstand voltage | |
| Dry | Min. 18 kVrms, Max. As per Requirement |
| Wet | Min. 8 kVrms, Max. As per Requirement |
| Creepage Distance | As per Requirement |
| Cantilever Load | Min. 12.5kN, Max. 18kN |
